Network Intrusion Detection System

01

The problem

Security classification needs more than a single overall accuracy number. This project separates the question of whether a connection is malicious from the harder task of identifying its attack family, especially when rare classes are underrepresented.

02

How it works

1. Inspect the official NSL-KDD train/test split, its 41 connection features, label imbalance, and attack types that appear only in testing.
2. Prepare numeric and categorical features, validating missing values and duplicates.
3. Compare Logistic Regression, Random Forest, and HistGradientBoosting for binary detection; compare tree-based models for multiclass diagnosis.
4. Export models, feature importance, and example connections for a Streamlit demonstration. A separate workflow examines suspicious patterns in web access logs.

03

Reported evaluation

On the repository's documented split, the binary HistGradientBoosting model reports 79.73% accuracy and 78.89% F1. The multiclass model reports 78.14% accuracy but only 55.98% macro F1. That gap makes the rare-class weakness visible rather than hiding it behind aggregate accuracy.

04

Limits

NSL-KDD is a learning benchmark, not a substitute for evaluating modern production traffic. The Streamlit app is a model demonstration, not a production intrusion-prevention system. Benchmark classification and heuristic web-log monitoring are separate capabilities and should not be conflated.
